BOT 208 Drainage Pump
BOT 208 heavy duty drainage pump for clean and dirty water designed for use in civil engineering, drainage of subway/tunnel for solid sediment, water treatment of ironworks, mobile use for drainage of public facilities, removal of sludge from rivers and other drainage.
BOT 208 heavy duty drainage pump for clean and dirty water
The BOT 208 is designed for use in civil engineering, drainage of subway/tunnel for solid sediment, water treatment of ironworks, mobile use for drainage of public facilities, removal of sludge from rivers and also other drainage.
There is a built-in overload protector therefore protecting the motor from over-heating and over-loading.
The inner cable wires and cable base are upgraded by filling EPOXY to raise humidity-resistance.
The motor frame and casing are both made of stainless steel and water.
The cooling jacket is designed for high efficiency of heat diffusion.
The stainless steel shaft is calibrated by dynamic balance test.
Dual mechanical seal SIC / SIC are installed and dual oil seals are designed to raise effects of dust-proof.
Impeller and agitator are both made of high chrome alloy steel (HCR) which produces high wear-resistance. The impeller is also calibrated by dynamic balance test.
The pump housing and stress eliminating plate are both made of high wear-resisting cast iron for durability, and an innovative design between pump housing bracket and mechanical seal lid to reduce flow stress and the life of the seals last longer.
|Model||kW||Outlet||Max. Flow||Max. Head|
|BOT 208||0.75 kW||2″||9.6 m3/h||8m|
