Control Box (Franklin Motor)

Control box to start and protect Single-phase 4″ PSC submersible motors (Franklin PSC water-cooled H3F motors).

Specification of the franklin electric control box franklin

• Electro-mechanical control box in thermoplastic shell, protection standard IP 55;
• Power inlet 1 x 230v;
• Start and run capacitor;
• 1.5 m cable supplied and with a UK plug also included;
• Inlet for connection to pressure switches or floating valves;
• Manually resettable thermic overload cut-off;
• Environmental temperature during use: from –10^oC to 40^oC.

Please note that the 03 single-phase ZDS motors require different control boxes than Franklin PSC single-phase motors. You can find these pumps in our website or contacting us. We are official Franklin Electric reseller

PEEL Pumps also makes customized control panels and offer remote monitoring
